Bosch Bosch ltc0498 / 51 series dinion2x day and night Camera




20 bit image processing technology

CCD sensor with wide dynamic range

Dynamic engine using smart BLC Technology

Detail enhancements

The mobile switching filter can realize real day and night performance



LTC 0498 dinion2x day night camera is a high-performance intelligent surveillance camera. It adopts 1 / 3-inch wide dynamic range CCD sensor and advanced digital signal processing (20 bit) technology, which can provide excellent image quality. 20 bit image processing technology improves sensitivity, while 2x ultra dynamic technology expands

Dynamic range. This unique combination enables the camera to produce clearer, more detailed and more realistic images under difficult lighting conditions.

Dinion2x camera is easy to install and can be put into use at any time, providing the best definition even in harsh scene conditions. Day and night performance ensures that extremely high-quality images can be taken at any time. It can automatically switch from color mode to black-and-white mode according to the lighting conditions of the surrounding environment.

All dinion cameras are ready for use at the time of delivery. Users only need to install the lens, connect the video and turn on the power. Six different cameras are preset in the camera

Operation mode of the. Please choose the mode suitable for your specific application for the best performance. The camera can automatically detect the lens type. The lens guide ensures accurate rear focus adjustment, so the camera can take a clear image at any time. When the conditions are particularly harsh, if fine adjustment or special settings are required, the user can use the control button on the side of the camera and the screen display menu (OSD) to adjust various parameters of the camera respectively.



basic function

Clear image details are presented under extreme lighting conditions. Under extreme lighting conditions, there may be great differences between the brightest and darkest parts of the scene. In order to generate clear images in these cases, the CCD sensor in dinion2x camera generates two images; The first image analyzes the details of the darkest area of the scene through long exposure, while the other image analyzes the details of the brightest area through short exposure. Dinion2x's data signal processing (DSP) technology combines these dual shutter images to mix each exposed pixel to produce the most detailed image. 20 bit image processing technology with high-precision digital signal processing technology, the camera can capture the best details in very bright areas and particularly dark areas. Due to the integration of 20 bit image processing technology and wide dynamic range, even under strong backlight,

Dinion2x also makes the image display as much information as possible.

Wide dynamic range

The excellent wide dynamic range can easily cope with all lighting conditions and present image details that could not be displayed before. 2X super dynamic range and smartblc use 2x super dynamic range technology, and the pixel by pixel analysis method can provide users with the most detailed information. Turning on smartblc can automatically carry out optical compensation for the image without complex settings and will not affect the dynamic range.

Detail enhancements

Automatic black level, excellent definition and other functions further improve the details in the scene from the pixel level.

Day / night mode

Day / night mode provides better night vision by increasing infrared sensitivity. By sensing the light intensity or through alarm input, the infrared filter can automatically switch from color mode to black-and-white mode. The filter can also be switched manually through the following methods: alarm input, camera menu or bilinx coaxial cable control interface. The lens infrared detector inside the camera can improve the stability of black-and-white mode, because it can prevent conversion to color mode when infrared light is dominant. In addition, the infrared contrast will be measured and used to process the reflected infrared light in the outdoor scene.

Privacy masking

Four different privacy area functions allow users to obscure specific parts of the scene. The user can preset the part of the scene to be obscured.

Default shutter

When the light is sufficient, the default shutter speed can shoot fast-moving objects. When the light intensity decreases and other possible adjustment methods are tried, if the requirements are still not met, the shutter speed will be converted to the standard setting to maintain normal sensitivity.

Bilinx communication technology

Bilinx is a two-way communication function through which data can be embedded into the video signals generated by all Bosch dinion cameras. Technicians can check the status, change camera settings and even update firmware from anywhere through the video cable. Bilinx reduces service and installation time, allows users to make more accurate settings and adjustments, and improves the overall performance of the camera. In addition, bilinx can use standard video cables to transmit alarm and status messages, so it can provide excellent performance without additional installation steps.

Lens Guide

The lens wizard can automatically detect the lens type and help users align the lens focal length with the maximum aperture, so as to keep the camera in the best focusing state within 24 hours a day. No special tools or filters are required.

Easy to install

The camera has several features that simplify installation.

? the power and alarm interfaces have cable connectors that can be removed even when the camera is installed.

? built in test mode generator can generate signals to test and find cable problems.

? multilingual on-screen menu (OSD) improves user compatibility.

Programmable mode

The camera is preset with six independent operation modes, which are respectively used in typical applications, but for some special occasions, the user is allowed to carry out comprehensive programming. These modes can be easily switched through bilinx or external alarm input.

Ultra efficient power supply improves the maximum operating temperature.

Video movement detection

The built-in video movement detector allows users to select programmable areas, and different thresholds can be set for each area. The full scene change detector can detect false alarms caused by sudden changes in lighting conditions, such as turning on or off indoor lighting devices or safety lighting devices, thus reducing the false alarm rate. When movement is detected, the system will display an alarm on the video monitor, turn off the output breaker, or transmit an alarm message through bilinx.

Sensitivity enhancement dynamics

By increasing the accumulation time on the CCD (up to 10 times), the effective sensitivity can be significantly increased. This is especially suitable for situations where the light source can only be provided by moonlight.

Typical applications:

? glass foyer or lobby

? outdoor perimeter protection

– low illumination

– infrared light

? traffic monitoring

– roads

– intersections



– emergency response coordination

? tunnels

? parking lot (outdoor)

? restricted access to places such as:

– prison

– port / cargo terminal

– military installations

– border control and Homeland Security

? casinos and gaming centers

Certificate and recognition

electromagnetic compatibility

Radiation en55022 class B, FCC Part 15 class B,

EN6100-3，EN50121-4

Immunity en50130-4 (CE), en50121-4 (CE)

The camera with 500g (1.1 lb) lens complies with

Iec60068-2-6 standard

security

LTC0498/11：UL1950-1，CSA 22.2 No. 950-1，EN60950-1

(CE)，UL60950，CAN/CSA No. 60950

LTC0498/51：UL1950-1，CSA 22.2 No. 950-1，EN60950-1

(CE)，EN61000-3-2 2000 +A2:2005，

EN61000-3-3 1995 +A1:2001 +A2:2005

Ltc0498 / 21 and ltc0498 / 61: ul1950-1, CSA 22.2 No. 950-1,

EN60950-1 (CE)，UL60950，CAN/CSA No. 60950

Regional certification

European CE compliance statement

Us UL

FCC Declaration of Conformity

Canadian CSA

2 | LTC 0498 series dinion2x day and night Camera



enclosure

Quantity component

1 LTC 0498 series dinion2x day and night Camera

1 C / CS - install conversion ring

1 male 4-pin lens connector

No lens available

technical specifications

Electrical index

Model rated voltage rated frequency

LTC 0498/11 24 VAC ±10% 50 Hz
12 VDC ±10%

LTC 0498/21 24 VAC ±10% 60 Hz

12 VDC ±10%

LTC 0498/51 230 VAC ±10% 50 Hz

LTC 0498/61 120 VAC ±10% 60 Hz

Power consumption 350 MA (12 VDC)

250 mA (24 VAC)

70 mA (120-240 VAC)

CCD type 1 / 3 inch interlaced transfer, WDR double shutter

Effective picture pixel

Pal model 752 x 582

NTSC model 768 x 494

Reflectivity (3200.89%, scene sensitivity)

Full video

(100 IRE)

Effective picture

(50 IRE)

Effective picture

(30 IRE)

Color 2.4 LX

(0.223 fc)

0.47 lx

(0.044 fc)

0.15 lx

(0.0139 fc)

colour

+10x sensitivity improvement

0.24 lx

(0.0223 f c)

0.047 lx

(0.00437 fc)

0.015 lx

(0.00139 fc)

Black and white 0.98 LX

(0.091 fc)

0.188 lx

(0.0174 fc)

0.060 lx

(0.0056 fc)

black and white

+10x sensitivity improvement

0.098 lx

(0.0091 fc)

0.019 lx

(0.00176fc)

0.0060 lx

(0.000557 fc)

Horizontal definition 540 TV line

SNR > 50 dB

Video output, composite video, 1 VPP, 75 ohms

In synchronization, line locking, HV locking and synchronous locking (pulse locking) can be selected, shutter automatic (1 / 50 [1 / 60] to 1 / 10000), optional automatic (1 / 50 [1 / 60] to 1 / 50000), automatic without stroboscopic, fixed mode sensitivity improvement, adjustable range: "off" to 10 times day / night color, black and white, automatic

Automatic black level automatically continuous, turn off the dynamic engine XF ultra dynamic, 2x ultra dynamic, smartblc dynamic range 120 dB (20 bit image processing) dynamic noise reduction can be selected automatically, turn on or off the sharpness, and select the sharpness enhancement level
Smartblc on (including 2x ultra dynamic range technology) / off

AGC can choose to turn AGC on or off (0 – 30 dB)

White peak suppression on / off

White balance ATW, atwheel and manual (2500 to 10000K)

Alarm output video movement detection or bilinx

Switching of different levels of alarm input (TTL), + 3.3V rated, + 40 VDC maximum

Alarm output relay 30 VAC or + 40 VDC, max. 0.5 a continuous, 10 VA

External synchronous input can choose 75 ohm or high resistance cable to compensate for up to 1000 meters (3000 feet) of coaxial cable without external amplifier (automatically set in combination with bilinx coaxial cable communication)

The camera ID is a 17 character editable field, and the position is optional

Test method generator: color bars 100%, grayscale 11 step

Sawtooth 2h, checker board, cross hatch, UV plane

Lens type automatically detects manual, DC and video aperture, and can rewrite DC aperture drive: maximum 50 Ma continuous current

Video aperture: 11.5 VDC ± 0.5, maximum 50mA continuous current lens mounting, CS type (lens maximum extension length of 5mm, 0.2 inch), C-type base, which can be connected with the attached

Use with adapter ring

Mode 6 preset modes

Remote control bilinx coaxial cable two-way communication

Video movement detection of an area, fully programmable

Privacy masking four independent areas, fully programmable

Control the on-screen menu operated by soft keys (Multilingual)

Mechanical index

Dimensions (H x W x L) 58 x 66 X122 mm (2.28 x 2.6 x 4.8 inches), excluding lens

Weight 450 g (0.99 lb), excluding lens

Color ral 9007 metal titanium tripod fixed bottom (isolation) and top 1 / 4 inch 20 UNC

Environmental requirements

Operating temperature - 20 ° C to + 55 ° C (- 4 ° f to + 131 ° f)

Storage temperature - 40 ° C to + 70 ° C (- 40 ° f to + 158 ° f)

Operating humidity 20% to 93% relative humidity

Storage humidity up to 98% relative humidity

Ordering Information

LTC 0498 / 11 dinion 2x day and night Camera

1 / 3 inch, advanced WDR, 540 TV cable, pal, 2x digital signal processing, 24 VAC / 12 VDC, 50 Hz

Order No. LTC 0498 / 11

LTC 0498 / 21 dinion 2x day and night Camera

1 / 3 inch, advanced WDR, 540 TV cable, NTSC, 2x digital signal processing, 24 VAC / 12 VDC, 60 Hz

Order No. LTC 0498 / 21

LTC 0498 / 51 dinion 2x day and night Camera
