WV-SFV533LH

Enhanced super dynamic full HD infrared anti riot network hemisphere camera

Full HD / 1920x1080 60fps H.264 enhanced super dynamic infrared anti riot network hemisphere camera

1080p Full HD real-time image up to 60fps * 1.

About 1 / 2.8 inch, high sensitivity MOS image sensor.

High sensitivity MOS sensor creates Full HD 1920x1080 ultra high resolution image.

H. 264 (high profile) (up to 4 streams) and JPEG multi stream output, synchronous real-time monitoring and HD video.

In 16:9 mode, the sub stream can also be selected 800x600@30fps *May 2015.

The maximum image size is 2048x1536 * @ 30fps, H.264.

*Super resolution technology

Compared with traditional cameras, enhanced super dynamic technology * 1 and ABS (automatic dark area compensation) technology can achieve 133dB wide dynamic range shooting.

MNR & 3d-dnr can reduce noise in many environments.

High sensitivity day night conversion function (infrared filter color to black): 0.07lux in color mode at f1.7; 01 lux in black and white mode.

Built in infrared LED light: the infrared LED light enables the camera to shoot at 0 lux at night.

It can automatically control the output power of the infrared LED light according to the surrounding environment, so that the camera can clearly capture the face image without overexposure.

The new camera mounting bracket provides a simple installation mode that can be controlled in four directions.

AF (auto focus) makes installation easy.

RS485 interface, can be used for two-way communication with banknote counter, access control and other RS485 devices.

AC 24 V / POE dual power interface, adapt to complex and diverse power environment.

Viqs (adjustable image quality of designated area) technology allows the designated eight areas to retain higher quality images, while the image quality of non designated areas is lower, and the file can be transmitted by a smaller code stream.

The screen clipping function can provide the whole image and local image at the same time. Up to 4 image capture areas can be specified, and their order can be controlled.

Facial super dynamic technology can ensure clear facial image.

256 level adjustment can compensate and correct the distorted image.

Electronic sensitivity enhancement: automatic (up to 16 / 30 seconds) / off.

Optional light control mode:

Outdoor, indoor (50 Hz) / indoor (60 Hz), fixed shutter

Indoor (50 Hz / 60 Hz): automatic compensation of fluorescent lamp flicker.

3 times extra optical zoom at 640X360 resolution.

2 x and 4 x electronic zoom controlled by browser.

VMD (video motion detection) has four areas, 15 levels of sensitivity and 10 levels of detection size.

The privacy area can cover 8 areas such as windows and entrances and exits.

Camera subtitle display: the browser can display up to 20 characters.

The alarm source includes three terminal inputs, VMD and Panasonic alarm instructions. These alarm sources can trigger SDXC / SDHC / SD memory card recording, FTP image transmission, email notification and browsing

The output of alarm terminal and Panasonic protocol.

Full duplex bidirectional audio can support the interactive communication between the front-end camera and the back-end monitoring platform.

JPEG image compression ratio can be changed by alarm signal to provide higher quality image.

Priority flow control: when multiple video recorders or client computers access cameras at the same time, one of the video streams can be set as priority, so as to ensure that the video recorder or client computer maintains a stable frame rate.

The SDXC / SDHC / SD memory card slot can be used for manual recording (H.264 / JPEG), alarm recording (H.264 / JPEG) and network fault recording (H.264 / JPEG). Realize long-term record and automatic backup function.

The newly developed spherical cover can provide a clearer image above the horizontal, thus expanding the tilt range of the lens.

The face detection function can detect the face position and send information through XML or video stream（ Optional wv-sae100 or wv-sae200)

In addition to the built-in VMD (video movement detection) and alarm function, new intelligent expansion software can also be added（ Optional (wv-sae200)

Through fog compensation function.

HLC (strong light suppression technology): if a strong light source (such as automobile headlight) shines on the camera, the camera can correct the strong light and its surrounding environment, so as to provide a clear image.

SCC (super chromaticity Compensation Technology) can achieve better color restoration even in low light.

H. 264 maximum bit rate / client and total bit rate control function can realize flexible network communication management. The frame rate priority mode controls the bit rate and compression ratio to provide a specific frame rate.

Internet mode: according to HTTP protocol, H.264 image can be transmitted.

Multilingual: Chinese / English / Italian / French / German / Spanish / Portuguese / Russian / Japanese.

Support IPv4 / IPv6 protocol.

DDNS (viewnetcam, rfc2136) is supported.

The still image (JPEG format) can be viewed online through mobile phone.

In accordance with onvif.

Comply with IP66 waterproof and dustproof standard. It is compatible with IEC60529 measurement standard.

Highly reliable anti riot equipment.

*1. Super dynamic function will automatically turn off in 60fps mode.

*1 conversion value.

*2. Super dynamic function will start automatically in 60fps mode.

*3 using Microsoft ? Windows ? 8 / Microsoft ? Windows ? 7 or Microsoft ? Windows Vista ? The CD-ROM contains information about the computer department

Pdf files required by the system and precautions.

*4. Four bit stream transmission can be set separately by the same compression method.
