WV-SFN533H

Enhanced super dynamic full HD network hemisphere camera

Full HD / 1920 × 1080 60fps H.264 enhanced super dynamic network hemisphere camera



1080p Full HD real-time image up to 60fps * 1.

About 1 / 2.8 inch, high sensitivity MOS sensor.

High sensitivity MOS sensor creates Full HD 1920x1080 ultra high resolution image.

H. High profile (up to 4 streams) and JPEG multi stream output for real-time monitoring and HD video recording.

In 16:9 mode, the sub stream can also be selected 800x600@30fps *June 2015.

The maximum image size is 2048x1536 * @ 30fps, H.264.

*Using super resolution technology

Compared with traditional cameras, enhanced super dynamic technology * 1 and ABS (automatic dark area compensation) technology can achieve 133dB wide dynamic range shooting.

MNR & 3d-dnr can reduce noise in many environments.

High sensitivity day night conversion function (infrared filter color to black)

When f1.7, it is 0.07lux in color mode; 01 lux in black and white mode.

AF (auto focus) makes installation easy.

RS485 interface, can be used for two-way communication with banknote counter, access control and other RS485 devices.

AC 24 V / DC 12 V / POE multi power interface, adapt to complex and diverse power environment.

Viqs (adjustable image quality of designated area) technology allows the designated eight areas to retain higher quality images, while the image quality of non designated areas is lower, and the file can be transmitted by a smaller code stream.

The screen clipping function can provide the whole image and local image at the same time. Up to 4 image capture areas can be specified, and their order can be controlled.

Facial super dynamic technology can ensure clear facial image.

256 level adjustment can compensate and correct the distorted image.

Electronic sensitivity enhancement: automatic (up to 16 / 30 seconds) / off.

Optional light control mode:

Outdoor, indoor (50 Hz) / indoor (60 Hz), fixed electronic shutter

Indoor (50 Hz / 60 Hz)

It can automatically compensate the flashing of fluorescent lamp.

3 x extra optical zoom at 640 x 360 resolution.

2 x and 4 x electronic zoom controlled by browser.

VMD (video motion detection) has four areas, 15 levels of sensitivity and 10 levels of detection size.

The privacy area can cover 8 areas such as windows and entrances and exits.

Camera subtitle display: the browser can display up to 20 characters.

The alarm source includes three terminal inputs, VMD and Panasonic alarm instructions. These alarm sources can trigger SDXC / SDHC / SD memory card recording, FTP image transmission, e-mail notification and browsing

Browser display, alarm terminal output and Panasonic protocol output.

Full duplex bidirectional audio can support the interactive communication between the front-end camera and the back-end monitoring platform.

JPEG image compression ratio can be changed by alarm signal to provide higher quality image.

Priority flow control: when multiple video recorders or client computers access cameras at the same time, one of the video streams can be set as priority, so as to ensure that the video recorder or client computer maintains a stable frame rate.

The newly developed spherical cover enables the camera to obtain clear images in a wider range of vertical angles, thus expanding the pitch range of the lens.

The face detection function can detect the face position and send information through XML or video stream（ Optional wv-sae100 or wv-sae200)

In addition to the built-in VMD (video movement detection) and alarm functions, new intelligent expansion software (wv-sae200 optional) can also be added.

Through fog compensation function.

HLC (strong light suppression technology): if a strong light source (such as automobile headlight) shines on the camera, the camera can correct the strong light and its surrounding environment, so as to provide a clear image.

SCC (super chromaticity Compensation Technology) can achieve better color restoration even in low light.

H. 264 maximum bit rate / client and total bit rate control function can realize flexible network communication management.

Internet mode: according to HTTP protocol, H.264 image can be transmitted.

Multilingual: Chinese / English / Italian / French / German / Spanish / Portuguese / Russian / Japanese.

Support IPv4 / IPv6 protocol.

DDNS (viewnetcam, rfc2136) is supported.

The still image (JPEG format) can be viewed online through mobile phone.

In accordance with onvif.

*1. Super dynamic function will automatically turn off in 60fps mode.

*1 conversion value

*2. Super dynamic function will be automatically set off in 60fps mode.

*3 using Microsoft ? Windows ? 8/ Microsoft ? Windows ? 7 or Microsoft ? Windows Vista ? The CD-ROM has information about electricity

Brain system and precautions required in PDF files.

*4. Four bit stream transmission can be set separately.
