Huawei 98010898 s1730s-l16p-ma 16 10 / 100 / 1000BASE-T Ethernet ports, Poe +, AC power supply Poe + monitoring private switch
1 PD compatibility test button
POE: turn off the compatibility detection function of PD devices. Only PD devices conforming to 802.3af or 802.3at standards can be powered.
L e-poe: enable the compatibility detection function of PD devices. The device can detect PD devices that do not conform to 802.3af or 802.3at standards (or switch devices can detect standard PD as non-standard PD after external influence), and supply power to these PD devices.
2 16 Poe + 10 / 100 / 1000BASE-T Ethernet interfaces
3 grounding screw, note: the minimum wire diameter required for grounding cable is 18awg.
4 AC power socket, note: use AC power cable.
Indicator light, the indicator light identification and meaning of s1730s-l16p-ma are the same as s1730s-l8p-a, please refer to the indicator light description of s1730s-l8p-a.
The power configuration of s1730s-l16p-ma device is built-in single AC power supply. S1730s-l16p-ma built in
In the power supply, 124W can be used for POE power supply. Under 802.3af protocol, it can support up to 8-port Poe full power supply, and under 802.3at protocol
At most 4-port Poe can be fully supplied under the same condition.
Heat dissipation principle: s1730s-l16p-ma equipment has no fan, and the heat dissipation type is natural heat dissipation.
98010898 s1730s-l16p-ma s1730s-l16p-ma 16 10 / 100 / 1000BASE-T Ethernet ports, Poe +, AC powered
Specification parameters
Overall dimension (width) × deep × (high)
L basic dimension (the depth is the distance between the structural parts excluding the front and rear panels): 442.0 mm × 220.0mm × 43.6mm
L maximum dimension (the depth is the maximum distance from the protruding port of the front panel to the protruding structural member of the rear panel): 442.0 mm × 225.7mm × 43.6mm
Weight (including packing material) 3.79kg
Service port lightning protection specification common mode ± 7kV
Power port lightning protection specification difference model ± 6kV, common mode ± 6kV
Poe support
Rated voltage range AC input: 100V AC ~ 240V AC; 50/60Hz
Maximum voltage range AC input: 90V AC ~ 264v AC; 47Hz～63Hz
Maximum power consumption (100% flow)
L without POE: 15W
Poe full load: 146w (POE: 124W) typical power consumption (30% flow) 14W
Operating temperature range - 5 ° C～+45 ° C (altitude from 0 m to 1 800 m) indicates that the maximum temperature specification decreases by 1 for every 220 m elevation from 1 800 m to 5 000 M ° C。
The device does not support operating at ambient temperatures below 0 ° It starts at C.
Storage temperature range - 40 ° C～+70 ° C
Room temperature noise
（27 ° C. Sound power
No fan, no noise
The relative humidity range is 5% RH ~ 95% RH, non condensing
The working altitude is from 0m to 5000m
Part code 98010898
