Panasonic wv-cs580 / CH indoor HD day and night high speed intelligent analog fastball camera
Wv-cs580 series
model:
WV-CS580/CH（AC220V~240V）
WV-CS584CH（AC24V）
Product Description:
Suitable for outdoor, super dynamic outdoor, day and night wide dynamic fastball camera.
Panasonic's super dynamic outdoor day and night wide dynamic fastball camera is equipped with protective cover, built-in integrated pan tilt and 36x optical zoom lens, which can rotate 360 degrees. Through the use of Panasonic's unique advanced functions (such as image contrast correction based on 160 times dynamic range of each pixel), excellent image accurate display is achieved. New intelligent functions include: automatic image stabilization, scene change detection and automatic tracking. Bring high reliability for outdoor monitoring. Wv-cw590 will play an active role in many security fields. It can be used to monitor parking lots, amusement parks, shopping malls, airports, railway stations, expressways, urban roads and squares.
Main features:
Panasonic's sixth generation super dynamic (sd6).
L built in integrated pan tilt, 360 degree rotation, 256 preset positions.
L horizontal definition: 650 lines.
L minimum illumination: 0.04lux.
L maximum 720x zoom (36x optical / 20x electronic).
High sensitivity day / night conversion function. (with infrared filter)
Intelligent function: automatic tracking function / scene change detection function.
L internal synchronization / multiplex vertical drive synchronization (VD2).
Multi channel coaxial or RS485 data communication.
Product features:
L wide dynamic range up to 80dB.
High resolution: 650tv line.
High sensitivity day / night conversion: 0.5 lux (color) and 0.04 lux (black and white) at f1.4 wide angle.
In black and white mode, turn the IR filter on / off to improve the sensitivity.
L adaptive digital noise reduction: 2d-dnr and 3d-dnr are combined to reduce noise under various conditions.
L electronic sensitivity improvement: automatic (up to 32 times) / manual (up to 512 times).
Electronic shutter: from 1 / 120 seconds to 1 / 10000 seconds.
36x optical zoom lens with 20x electronic zoom.
L maximum rotation / pitch speed: 400 ° / S (preset mode); 0.065 ° / S (hyperfine manual mode).
The angle of view with high 5 degrees can adapt to a wider range.
L 256 preset bits.
Automatic tracking: the maximum range of automatic tracking image of the camera, which is always placed in the center of the screen through rotation / pitch.
L VMD shielding area 8x6.
Scene change detection alarm: when the lens is blocked, sprayed, removed, defocused or damaged.
4 alarm inputs and 2 alarm outputs.
L alarm linkage includes: port output, camera position adjustment, automatic rotation, inspection, sequence, sorting, automatic tracking, black and white and command output.
L automatic image stabilizer: it can be used in case of vibration and strong wind.
Synchronization within L.
L coaxial cable or RS-485 data communication.
L 16 character camera title display.
Multiple language settings: Chinese, English, French, Italian, Spanish, German, Russian, Japanese.
Specification parameters:
model
WV-CS580/CH
WV-CS584CH
Pick up device
1 / 4 type interline transfer CCD
Effective pixel
976(H)×582(V)
Scanning range
3.66(H)×2.73(V)mm
signal
PAL
synchronization
Internal synchronization (int)
Scanning mode
2: 1 interlaced scan
Scanning frequency
Horizontal: 15.625kHz vertical: 50Hz
Video output
VBS:1.0V [P-P] / 75 Ω (BNC port)
resolving power
650 lines (color mode, high mode)
Minimum illumination
0.5Lux in color mode and 0.04lux in black and white mode
dynamic range
80dB (6th generation super dynamic: on)
Signal to noise ratio
Minimum 50dB (AGC: off)
Rotation range
360 ° infinity
Rotation mode
Manual, automatic, manual preset call, sequence preset switch
Rotation speed
Manual: 0.065 ° / S ~ 120 ° / s, preset position of level 8, level 16 and level 64: 400 ° / s
Pitch angle
-5 ° to 185 ° depending on pitch angle
pitch mode
Manual, automatic, manual preset call, sequence preset switch
Pitching speed
Maual: 0.065 ° / S ~ 120 ° / s, preset position of level 8, level 16 and level 64: 400 ° / s
Zoom ratio
36x optical zoom + 20x electronic zoom
focal length
3.3mm~119mm
Maximum aperture ratio
1: 1.4 (wide angle) ～ 4.2 (telescope)
Minimum object distance
1.5m
Aperture range
F1.4-22, off
visual angle
Horizontal: 1.7 ° to 60.2 ° wide angle vertical: 1.3 ° to 46 ° wide angle
control mode
Multiplex coaxial, RS-485
control function
Rotation / pitch, zoom and focus, 256 preset positions, base point position, patrol position
AGC
On (low / medium / high), off
Character display
On, off (preset ID, camera ID, area name: 16 characters)
Zoom speed
About 6.0 seconds in manual mode (telescope / wide angle)
Zoom ratio control
1-720 times (more than 36 times is electronic zoom)
Password lock
All menus
Autofocus
Auto zoom / auto zoom
aperture
ALC (adjustable on / off output target level) / manual
Electronic shutter
Off (1 / 50), auto, 1 / 120, 1 / 250, 1 / 500, 1 / 1000, 1 / 2000, 1 / 4000, 1 / 10000 seconds
Enhancement of electronic sensitivity
Maximum 32 times (automatic) 512 times (fixed)
Automatic mod
Close, sequence, sort, auto rotate, patrol, auto track
Auto Key
Sequence, sorting, automatic rotation, patrol, automatic tracking
Digital Flip
On / off
Super news of the 6th generation
On / off
Mobile detection
On / mode 1 / mode 2
Alarm I / O
4-way input (alarm 1-alarm 4) 2-way output (alarm / auxiliary 1 and black-and-white / auxiliary 2)
Black and white mode conversion
Auto / on / off
Privacy zone
Up to 8 zones on / off
Inspection tour
Stop / play / learn
clean
On / off
Image retention
On / off
Automatic image stabilizer
On / off
Scene selection settings
Indoor (low) / indoor (high) / outdoor (low) / outdoor (high)
Language settings
chiese
Working environment temperature
-10℃~+50℃
Working environment humidity
Maximum 90% (non condensing)
Power Supply
AC 220V～240V, 50Hz
AC 24V，50Hz
power waste
80W
98W
size
Φ200mm(D) ×360mm(H)
Weight (about)
About 4kg
