Conway technology - sales of axis q8675-ze Mk III 9931-009 webcam
Pan tilt integrated camera for object viewing in mission critical environment
The axis q8675-ze Mk III PTZ webcam provides fast horizontal and vertical movement and excellent low illumination imaging capability,
Through 1 / 1.9 inch image sensor and axis "light seeker" imaging technology, clear color image can be obtained even in weak light environment
Like. The unique mechanical design helps the camera to work stably in all kinds of environments, and it can still operate normally under the wind speed of 140kph, and at the same time
Through the built-in wiper and fog function, the monitoring ability of the camera in rainy and foggy days is effectively improved. The camera provides a wealth of external connections
Port, including: SD card slot for front-end storage, audio and I / O alarm, and 24 V AC and 24 V DC power interface. Therefore, axis
The q8675-ze Mk III PTZ webcam is a better choice for mission critical environments such as roads, airports and safe cities.
>HDTV 1080p, up to 30x zoom
>Axis "light seeker" technology
>360 ° continuous horizontal movement
Electronic image stabilization and fog penetration
>Waterproof, dustproof, wiper function
>xis zipstream zipstream zipstream technology, H.264 and h.265
video camera
Image sensor 1 / 1.9 inch progressive scan RGB CMOS
Lens: 6.7 – 201 mm: 58.6 ° to 2.2 ° viewing angle a, a, f1.6 – 5.3, auto focus, auto day night switching
Day and night: automatically removable infrared cutoff filter
Minimum illumination: Color: 0.05 lux 30 ire f1.6 black and white: 0.005 lux 30 ire f1.6
Shutter time: 1 / 10000 seconds to 1 second
video
Video compression: H.264 (MPEG-4 Part 10 / AVC) baseline, main and high profiles
H.265 (MPEG-H Part 2/HEVC) Main Profile Motion JPEG
Resolution: 1920x1080 (HDTV 1080p) to 320x180
Frame rate: h.264/h.265/motion JPEG: maximum 50 FPS (50 Hz) multi channel configurable H.264, h.265 and motion JPEG video streams in various resolutions, axis zipstream technology,. 264 and h.265 controllable frame rate and bandwidth, VBR / ABR / MBR h.264/h.265
Image settings: manual shutter time, compression ratio, color, brightness, sharpness, white balance, exposure control, exposure area, backlight compensation, WDR 120dB, behavior fine-tuning under low illumination, rotation, text and image superposition, privacy mask, day / night switching level, electronic image stabilization function, automatic fog transmission function
Pan / tilt / zoom: 360 ° continuous horizontal rotation, manual control 0.05 ° / s to 80 ° / s – 75 ° to 40 ° vertical rotation, manual control 0.05 ° / s to 60 ° / s 256 preset positions, preset speed: horizontal 0 ° / s, vertical 60 ° / s, preset accuracy: ± 0.1 ° 30x optical zoom, 21x word zoom
audio frequency
Audio stream: bidirectional, full duplex
Audio compression: aac-lc 8 / 16 kHz, G.711 PCM 8 kHz, G.726 adpcm8 kHz, configurable bit rate
Audio input: 3.5mm microphone / line in Jack, maximum 80 mVpp
Audio output: 3.5mm line output jack, maximum 2.8 VPP
network
Security: password protection, IP address filtering, httpsb encryption, IEEE 802.1xb network access control, digest authentication, user access log, centralized certificate management
Supported protocols: IPv4 / v6, HTTP, httpsb, SSL / tlsb, QoS layer 3, DiffServ, FTP, SFTP, CIFS / SMB, SMTP, Bonjour, upnptm, SNMPv1 / V2C / V3 (mib-ii), DNS, dyndns, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, socks, SSH, NTCIP, lldp
system integration
Application programming interface: open API for software integration, including vapix? And axis camera application platform, see www.axis.com For details, refer to www.onvif.org
Intelligent analysis: video motion detection, perimeter protection, wandering detection, guard, active tamper alarm, axis camera application platform, support the installation of additional intelligent application software
Event trigger: intelligent video, front-end storage events, external input
Event action: day and night mode, character overlay, file upload: FTP, SFTP, HTTP, HTTPS, network sharing and e-mail notification: e-mail, HTTP, HTTPS and tcpptz: PTZ preset, start or stop patrol external output, activate video and audio recording to front-end storage, and send SNMP traps through video buffer before and after alarm,
Data flow: event data
Built in installation help: pixel counter, level adjustment wizard
routine
Enclosure: IP66 and NEMA 4x seismic aluminum enclosure, color: white NCS s 1002-b, integrated wiper
Memory: 1GB ram, 512 MB flash memory
Power supply: maximum 65W, 24 V DC, 24 V AC
Interface: RJ45 10Base-T / 100base-tx interface * 1, audio input * 1, audio output * 1, DC / AC power interface * 1, RS485 interface * 1, I / O interface * 1
Storage: SD / SDHC / SDXC slot, support SD card encryption, support recording to NAS SD card and NAS recommended axis.com
Working conditions: - 30 ° C to 50 ° C, support defrosting function, humidity 10 – 85% relative humidity (condensation) wind resistance: more than 12 levels, can maintain operation at 140 kph wind speed
Certification: type I test report, gb28181
Dimensions: 190mm (L) * 456.5mm (H) * 66.7mm (d)
Weight: 10.6kg
Accessories included: screw set * 4 hexagon wrench * 1 installation guide * 1
Optional accessories: axis t91x81 wall bracket wiper front window glass
Video management software: the video management software provided by axis camera company (including), axis camera station and axis application development partners (excluding). For more information, please visit www.axis.com/products/video/software
Warranty: axis 3-year warranty and extended warranty are available. For details, please visit www.axis.com/warranty
The warranty period of wiper is one year
AXIS Q8675-ZE MK III CN 20 9931-009 PT head camera, 30X zoom, 1080p@50fps , 1/2 inch image sensor, lightfinder, WDR, wiper, auto-defogging, image stabilizer. Outdoor ready. For China market only.23,908 CN: 9931-009 .
